Fingerprint Sensor

LENano

LEnano sensors uses patented LES technology which has the highest captured Image quality and can capture dry fingers with no membranes required

LEnano7

Optimized for mobile phones & Smart Card

  • IC package type & Sensor type

  • Compact size with small-footprint packages

  • Strong in dry finger

FRONT

BACK

LEnano8

Optimized for PCs, Embedded devices

  • IC package type & Sensor type

  • High performance, rugged, durable at competitive price

  • Strong in dry finger

FRONT

BACK

LEnano12

High-performance Optical Fingerprint Sensor

  • Thinnest optical sensor

  • Excellent with dry and dirty fingers

  • Operates in direct sunlight

  • Requires no cleaning for latent fingerprints

  • Easy to integrate

  • Small form factor

  • Counterfeit finger rejection

  • Rotation invariant

  • High durability surface

FRONT

BACK

Specification

Optimized for mobile phones & Smart Card

Model

Type

Operating Voltage

Consumption Power

Resolution

508PPI, 1016PPI

< 0.01W

1.8V

LES + CMOS

LEnano7

Sensor Dimensons(mm)

8.4(W) x 5.1(L) x 1.0(H)

7.5 x 4.0

Active Area(mm)

Operating Temperature

-20C ~ 60C

20~95% RH < 50C

Huidity

Interface

SPI

Specification

Optimized for PCs, Embedded devices

Model

Type

Operating Voltage

Consumption Power

Resolution

508PPI

< 0.01W

3.3V

LES + CMOS

LEnano8

Sensor Dimensons(mm)

10.5(W) x 9.0(L) x 1.0(H)

8.8 x 8.0

Active Area(mm)

Operating Temperature

-20C ~ 60C

20~95% RH < 50C

Huidity

Interface

SPI

Specification

High-performance Optical Fingerprint Sensor

Model

Type

Operating Voltage

Power Consumption

Resolution

500PPI, 1000PPI

< 76mA

3.3V

Light Emitting Sensor

LEnano12

Sensor Dimensons(mm)

31.7~36.9(W) x 18.2(L) x 10.7(H)

12.0 x 12.0

Active Area(mm)

Operating Temperature

-20C ~ 60C

-40C ~ 80C

Storage Temperature

Interface

8bit Parallel
