Fingerprint Module SLM-12 Series

SLM-12 Series is high-end fingerprint module with patented LE technology and CMOS Image sensor.
SLM-12 series is used as one fingerprint scanner and embedded module with reliable and field-proven algorithm for quick and accurate authentication

SLM-12B

high-end fingerprint module

​

  • The world best image quality(Electroluminescense+Optical

  • Impervious to bright and lights/sunlight

  • High durability surface

  • Unaffected by latent prints on platen

  • Captures dry fingers with no membranes required

  • Module with matching algorithm

  • Thinnest optical sensor

​

​

Inquiry

SLM-12C

quick and accurate authentication

  • The world best image quality(Electroluminescense+Optical

  • Impervious to bright and lights/sunlight

  • High durability surface

  • Unaffected by latent prints on platen

  • Captures dry fingers with no membranes required

  • Module with matching algorithm

  • Thinnest optical sensor

​

※ Embedded device with PFCB cable

Inquiry

Specification

Patented LE technology and CMOS Image sensor

Sensor

Main CPU

Interface

Size(mm)

Consumption Power

SLM12B : 0.75W, SLM12C : 0.8W

49.2(W)x35(L)x18.2(H)

USB2.0

ADSP-BF70x

LEnano12 (Light Emitting Sensor(LES) + CIS)

Inquiry

Operating Voltage

-20C ~ 60C

Operating Temperature

Operating Humidity

20~95% RH < 50C

Max 10uA

Sleep Current

※ SLM-12B, 12C: USB 2.0 interface, Scanner / eSLM-12B, 12C: UART interface. Embedded module

Specification

Patented LE technology and CMOS Image sensor

Sensor

Main CPU

Interface

Size(mm)

Consumption Power

SLM12B : 0.75W, SLM12C : 0.8W

126.4(W)x35(L)x18.2(H)

UART

ADSP-BF70x

LEnano12 (Light Emitting Sensor(LES) + CIS)

Inquiry

Operating Voltage

-20C ~ 60C

Operating Temperature

Operating Humidity

20~95% RH < 50C

Max 10uA

Sleep Current

※ SLM-12B, 12C: USB 2.0 interface, Scanner / eSLM-12B, 12C: UART interface. Embedded module

SLM12B, SLM12C

Item

Item

eSLM12B, eSLM12C
